Are drafting chairs worth it? The answer depends on one measurement
Summary
- Drafting chairs are worth it whenever the work surface exceeds 850 mm in height
- The foot ring, not the extra height, is what prevents leg and lower back fatigue
- Expect to pay $100 to $250 more than the equivalent standard height chair
A drafting chair is worth the extra cost when staff work at a raised bench, counter or standing desk. Below 850 mm, a standard chair does the job for less. Above it, a drafting chair with a foot ring is the difference between supported legs and dangling ones. Browse stocked drafting chairs with 3 to 5 working day delivery Australia-wide.
Shop the drafting range
- Drafting chairs - high gas lift and adjustable foot ring for bench height work
- Sit stand stools - perching seating for short-duration tasks
- Saddle stools - upright posture for close hands-on work
- Laboratory seating - drafting heights with wipe-clean surfaces
- Accessories - retrofit foot rings, castors and glides
What is a drafting chair?
A drafting chair is a chair fitted with a high reach gas lift and a foot ring, built for working at bench height rather than desk height. The name comes from draftsmen who drafted large format plans on long sloping desks and needed to sit higher to do it.
Today the term covers any raised seating with those two features. The foot ring is separately height adjustable up and down the gas lift stem, which matters more than most buyers expect. Most Australian benches sit at 900 mm, and the drafting chair range is built for exactly that.
Are drafting chairs worth the extra cost?
Yes, in four specific situations. No, in one.
- Yes, when the work surface sits above 850 mm and staff sit for extended periods
- Yes, when the same station is shared across shifts by people of different heights
- Yes, when staff alternate between sitting and standing at the same bench
- Yes, when reach and sightline over the bench affect the quality of the work
- No, when the surface is a standard 720 to 750 mm desk, where a standard chair is better and cheaper
The cost gap is real but modest. A Heavy Duty Lab Chair in standard height and the same model as a Heavy Duty Lab Drafting Chair differ by around $50. Both carry AFRDI Level 6 approval and a ten year warranty. On a ten year horizon, that is a rounding error against the cost of one staff member off work with a back complaint.
Why does the foot ring matter more than the height?
Raise a person to bench height without supporting their feet and you have created a new problem, not solved the old one. Unsupported legs load the back of the thigh, restrict circulation and pull the pelvis into a posterior tilt. The lower back rounds. Within an hour the user starts shifting and fidgeting.
An adjustable foot ring restores the support the floor used to provide. Set it so the thighs run roughly parallel to the ground with the feet flat on the ring. The ring on models such as the Gala Lab Drafting Chair is heavy duty and adjusts independently of the seat, which is what makes shared use practical.
If you already own high seating without a ring, a chrome chair footring fits over a 457 mm gas lift and suits most office chairs. At around $53 it is the cheapest ergonomic fix available.
How do you know if you need one? Measure first.
One measurement decides it. Measure from the floor to the top of the work surface.
| Surface height | Verdict | What to buy |
|---|---|---|
| 720 to 750 mm | Not worth it | Standard height task or lab chair |
| 850 to 950 mm | Worth it | Drafting chair with adjustable foot ring |
| 1000 mm and above | Worth it | Drafting chair or sit stand perching stool |
| Adjustable sit stand desk | Worth it | Drafting chair covering the full range |
What does a drafting chair cost in Australia?
Four price bands cover almost every requirement.
| Price band | What you get | Warranty | Suits |
|---|---|---|---|
| Under $200 | PU padded stool, foot ring, no backrest | 3 years | Short tasks, workshops |
| $220 to $280 | Polypropylene seat and back, ring mechanism | 10 years | Labs, education, production |
| $360 to $420 | AFRDI Level 6, two-lever, lumbar support | 10 years | Full shift, shared use |
| $390 to $500 | Three-lever ergonomic, mesh or vinyl, optional arms | 3 to 10 years | Long seated periods, clinics |
The Strong Industrial Padded Stool sits in the first band at around $172, with a 650 to 870 mm height range and a 120 kg load rating. The Sit Stand Lab Chair occupies the second band and carries a ten year warranty, which is unusual at that price.
Who actually benefits from a drafting chair?
- Laboratory technicians working at 900 mm benches for full shifts
- Dental, physio and medical staff who need reach and sightline over a patient
- Warehouse and production staff at raised packing, QA and assembly stations
- Designers, drafters and architects working at sloped or raised drawing surfaces
- Retail and hospitality staff at service counters and point-of-sale stations
- Teachers and students at science bench height in education facilities
For retail counters specifically, the retail seating range covers perching and counter stools. For clinical settings, the healthcare range includes drafting heights with antibacterial surfaces.
When is a drafting chair the wrong choice?
Three situations where the money is better spent elsewhere.
- Standard desks, where the extra height forces the user to drop the seat to its lowest setting
- Very short duration perching, where a sit stand stool with lip is lighter and cheaper
- Low ceiling mezzanines or under-shelf stations where headroom is the limiting factor
There is also a middle option many buyers miss. A saddle stool in drafting height, such as the Uplifting Rodeo 2.0 Drafting Saddle Stool, gives the height without the bulk of a full backrest chair. It suits close hands-on work at 685 to 800 mm.
Why Industry Chairs is trusted. Built for reliability. Delivered without delays.
Industry Chairs is part of JasonL, which means specialist industrial seating backed by a national furniture operation.
- Delivery in 3 to 5 working days on stocked items across Australia
- Stock held in our Sydney warehouse rather than indented from overseas
- Australia-wide coverage across all capital cities and major regional centres
- Professional installation available on request
- Warranties from 3 to 10 years depending on model, with 10 year cover on applicable products
- AFRDI Level 6 approval on heavy duty drafting models, compliant with Australian and New Zealand standards
- ISO 9001 and ISO 14001 certified manufacturing across the core range
- Standard 120 kg load rating, with seating rated for 8 or more hours daily use
- Foot rings, castors, glides and arms configured before dispatch rather than retrofitted
- Direct phone support on 1300 527 665 for bench height and specification questions
How Industry Chairs compares to other suppliers. Clear differences. No noise.
Buyer decision snapshot
- Measure your bench before you compare any two drafting chairs on price
- Confirm the foot ring adjusts independently, not fixed to the base
- Buy from a supplier holding local stock if you need chairs this month
- Compare warranty length at equivalent price points, not headline discounts
- Check whether castors are configurable for your specific floor surface
| Criteria | Industry Chairs | Large national office supplier |
|---|---|---|
| Drafting range depth | Dedicated drafting category across stools, saddles and chairs | One or two drafting lines within a general catalogue |
| Foot ring adjustability | Independently adjustable up and down the gas lift stem | Often fixed position or not supplied |
| Delivery timeframe | 3 to 5 working days on stocked items | Varies by line, indent items often 4 to 8 weeks |
| Warranty coverage | 3 to 10 years depending on model | Commonly 1 to 5 years |
| Assembly requirement | Minor assembly, professional installation available | Flat-pack delivery, installation rarely offered |
| Specification advice | Direct help matching seat range to bench height | General sales support |
| Best suited to | Labs, workshops, clinics, production and retail counters | General office desks |
Frequently asked questions
Are drafting chairs worth it for a standing desk?
Yes, if the desk spends much of its time in the raised position. A drafting chair lets staff perch or sit at standing height without lowering the desk, which is the main reason people abandon sit stand desks. Choose a model covering the full range, such as the Uplifting Sit Stand Drafting Stool with Lip at 565 to 825 mm. If the desk stays low most of the day, a standard chair is the better buy.
What height should a drafting chair be for a 900 mm bench?
Look for a seat height range that tops out between 850 and 900 mm, giving roughly 250 to 300 mm of clearance under the bench. The Gala Lab Drafting Chair adjusts from 590 to 850 mm and suits this directly. Set the foot ring so the thighs sit roughly parallel to the floor once the seat height is correct. Adjust the ring for each user in shared environments.
How much more does a drafting chair cost than a standard chair?
Typically $50 to $150 more for the same model in drafting height. The premium covers the longer gas lift, the foot ring and the wider base needed for stability at height. Across a ten year warranty period that difference is negligible. Buying a standard chair for a bench and watching staff perch on it costs considerably more in the long run.
Do drafting chairs tip over?
Not when correctly specified. Drafting chairs use a wider base than standard chairs precisely to counter the higher centre of gravity. The models in our range use 600 mm and 640 mm nylon five-star bases. Risk rises if you retrofit a long gas lift into a chair designed for standard height, which is why we do not recommend that approach.
Can I add a foot ring to a chair I already own?
Often yes. The chrome chair footring fits over a 457 mm gas lift and suits most office chairs, adding leg support for around $53. Check your gas lift diameter and length before ordering. If the existing chair has a standard height gas lift, a foot ring will not help, because the chair cannot reach bench height in the first place.
What is the difference between a drafting chair and a sit stand stool?
A drafting chair is a full chair with a backrest, a wide base and a foot ring, built for sustained seated work at height. A sit stand stool is a perching seat designed to take partial weight while the user remains largely upright, suited to shorter tasks. The sit stand stools range is lighter and cheaper, while the drafting chairs range is the choice for full shifts.
Which castors should a drafting chair have?
Match the castor to the floor. Soft castors suit hard surfaces such as vinyl, epoxy, timber and sealed concrete, while hard castors suit carpet. Glides are the right call where the chair should stay in one place at a fixed station. Most models let you select this at the point of order, and replacement castors, glides and accessories are stocked separately.
How long does delivery take on drafting chairs?
Stocked items ship in 3 to 5 working days Australia-wide, from our Sydney warehouse. That covers Sydney, Melbourne, Brisbane, Perth, Adelaide, Canberra and major regional centres including Newcastle, Wollongong, Geelong and the Gold Coast. Configured orders across multiple options may take slightly longer, and the team will confirm at the time of order.
